Description
| MODELS SPEC. | 9-27X56ED | 12.5X56ED | 8-24X50ED | 12X50ED | 11-33X56ED | 15X56ED | |||||||
| M99-92756 | M99-12556 | M99-82450 | M99-1250 | M99-113356 | M99-1556 | ||||||||
| 01 | POWER | 倍 率 | 有效倍数 | 9x | 27x | 12.5x | 8x | 24x | 12x | 11x | 33x | 15x | |
| 02 | OBJ.LENS DIA. | 物镜直径 | mm | 有效直径 | 56mm | 56mm | 50mm | 50mm | 56mm | 56mm | |||
| 03 | TYPE OF PRISM | 棱镜类别 | Type / Material | 类别及材料 | BK7 | BK7 | BK7 | BK7 | BK7 | BK7 | |||
| 04 | PRISM COATING | 棱镜镀膜 | Yes / No | 是或否 | yes | yes | yes | yes | yes | yes | |||
| 05 | NUMBER OF LENS | 透镜组数 | Pieces & Groups | 共多少片及分多少组 | 11pieces7groups | 10pieces8groups | 11pieces7groups | 10pieces8groups | 11pieces7groups | 10pieces8groups | |||
| 06 | LENS COATING | 透镜镀膜 | CL/FC/BMC/FBMC | 部分或全部或多层膜 | FMC | FMC | FMC | FMC | FMC | FMC | |||
| 07 | FOCUS SYSTEM | 调焦系统 | Cent. / Ind. / Fix | 中调或分调或定焦 | Int. | Int. | Int. | Int. | Int. | Int. | |||
| 08 | FOCUSING LENS | 调焦透镜 | Eye. / Obj. / Int. | 目镜或物镜或内调 | Obj.Int. | Obj.Int. | Obj.Int. | Obj.Int. | Obj.Int. | Obj.Int. | |||
| 09 | EXIT PUPIL DIAMETER | 出瞳直径 | mm | 6.2 | 2.1 | 4.4 | 6.2 | 2.1 | 4.4 | 5.4 | 1.8 | 3.8 | |
| 10 | EXIT PUPIL DIST. | 出瞳距离 | mm | 19.8 | 16.7 | 18.4 | 20 | 16.7 | 18.5 | 19.4 | 16.8 | 18.2 | |
| 11 | FIELD OF VIEW | 视 场 | ANGLE | 角度 | 4.6° | 2.3° | 5.3° | 4.9° | 2.5° | 5.7° | 4.1° | 2.2° | 4.5° |
| 12 | Ft / 1,000Yds | 尺 | 241 ft | 120 ft | 278 ft | 257 ft | 131 ft | 299 ft | 215 ft | 115 ft | 236 | ||
| 13 | M / 1,000M | 米 | 80m | 40m | 93m | 86m | 44m | 100m | 72m | 38m | 79m | ||
| 14 | MIN.FOCAL LENGTH | 最近焦距 | M / Ft. | 米 / 尺 | 2.5m | 2.5m | 2.5m | 2.5m | 2.5m | 2.5m | 2.8m | 2.8m | 2.8 |
| 15 | RELATIVE BRIGHTNESS | 相对亮度 | |||||||||||
| 16 | TWLIGHT INDEX | 黄昏指数 | |||||||||||
| 17 | RESOLUTION | 分辨率 | 3.2" | 3.2" | 3.6" | 3.6" | 3.2" | 3.2" | |||||
| 18 | DIOPTER SYSTEM | 视差补偿 | 左或右的目镜或物镜 | ||||||||||
| 19 | DIOPTER COMP. | 视差度数 | ±Optic.Degree | ||||||||||
| 20 | INTERPUPILLARY DIST. | 目镜相距 | mm | 最阔及最窄时 | |||||||||
| 21 | ZOOM SYSTEM | 变焦系统 | Type & Location | 线性或分段 | 线性 | 线性 | 线性 | ||||||
| 22 | WEATHER PROOF | 全 天 候 | Yes / No | 1m/30min | 1m/30min | 1m/30min | 1m/30min | 1m/30min | 1m/30min | ||||
| 23 | WATER PROOF | 防水结构 | Depth / Time | 深度及时间 | |||||||||
| 24 | NITROGEN FILLED | 氮气充存 | Yes / No | 有或无 | yes | yes | yes | yes | yes | yes | |||
| 25 | EYECUPS SYSTEM | 目罩结构 | Rubber / Pop-up / Twist-up | 可反接橡胶/拉出/旋出 | Twist-up | Twist-up | Twist-up | Twist-up | Twist-up | Twist-up | |||
| 26 | POUCH | 软 包 | Yes / No-Mat'l. | 有或无及材料 | yes | yes | yes | yes | yes | yes | |||
| 27 | STRAP | 手 带 | Yes / No-Mat'l. | 有或无及材料 | yes | yes | yes | yes | yes | yes | |||
| 28 | CLEANING CLOTH | 清 洁 布 | Yes / No | 有或无 | yes | yes | yes | yes | yes | yes | |||
| 29 | SILICA GEL | 干 燥 剂 | Yes / No | 有或无 | yes | yes | yes | yes | yes | yes | |||
| 30 | UNIT DIAMENSION | 产品尺寸 | mm | 198X135X67 | 182X118X67 | 186X135X63 | 170X118X63 | 224X135X67 | 209X118X67 | ||||
| 31 | UNIT WEIGHT | 产品重量 | gm / oz. | ||||||||||
| 32 | GIFT BOX SIZE | 彩盒尺寸 | mm | ||||||||||
| 33 | PIECES PER INNER CARTON | 内箱件数 | Pieces / Size | 只数及尺寸 | |||||||||
| INNER CARTON SIZE | 内箱尺寸 | ||||||||||||
| 34 | PIECES PER SHIPPING CARTON | 装箱件数 | Pieces | ||||||||||
| 35 | SHIPPING CARTON SIZE | 装箱尺寸 | Size | cm | |||||||||
| 36 | GROSS WEIGHT | 毛 重 | Kg. / Pound | ||||||||||
| 37 | NET WEIGHT | 净 重 | Kg. / Pound | ||||||||||
