Description
Edgeless Image,
Return to Zero Adjustment Plate,
Super Bright Clear,
Designed for 30 to 300 Yards Shooting,
4" Long Eye Relief,
30mm Monotube,
FD7 Style Etched Glass Reticle
Model Number
1-5X24
Magnification
1-5x
Objective Lens Dia
24mm
Ocular Lens Dia
33mm
Ocular Lens Length
80mm
Exit Pupil
17.5-5.23mm
Optics Coating
Fully-multi coated
Field of View
73.3-19.9 feet @ 100 yards
Eye Relief
115-95mm (4.5-3.7")
Length
265mm 10.4 inch
Weight
415g 14.6oz
Tube Dia.
30mm Monotube
Click Value
1/2 MOA
Number of MOA per dial rotation
30
Elevation Range
60MOA
Windage Range
60MOA
Parallax Setting
100 yards
Reticle
Etched glass
Illumination
11 levels red
Battery
CR2032
Number of Lens: 12 pcs
Shock tested to 750g, water proof at 300 meters and 54 degree
Fully nitrogen purged to eliminate any fogging of the lenses internally
Adjust plate is NOT fixed, after zero the scope you can turn the plate to zero
High quality 6061 T6 aircraft grade aluminum
Designed for close and mi-range shooting
Diopter compensation from fast-focus eyepiece (+2 to -2)
Including items: 30mm mount rings , cleaning cloth, lens cap,packaged in nice gift box
